Tow tractors P120 – P350

Powerful load handler

Heavy goods moved easily

The robust and powerful P120 – P350 electric tow tractors transport loads of up to 35 tons at top speeds of up to 25 kilometres per hour. Six models with different towing capacities ensure a perfect match for any application. The models with a short wheelbase are easy to manoeuvre in tight spaces, the models with long wheelbases feature especially high directional stability. Their powerful electric motors enable consistently high towing performance, even when operating on gradients. That makes them ideal for wholesale markets or airports as well as for production supply. A cabin decoupled from the chassis as well as a drive axle equipped with coil springs instead of leaf springs prevents shocks from being transmitted to the operator when travelling on uneven ground. This significantly reduces the physical strain on the operator. In addition, the construction of the chassis allows changing the battery from above or from the side. The P120 – P350 tow tractors can be powered by lead-acid or lithium-ion batteries.

Characteristics

Safety

The P120 – P350 tractors have three independent braking systems to ensure the safe transport of heavy loads. The operator activates the multi-disc brake via the foot pedal. The reverse current brake starts to slow the truck down as soon as the operator releases the accelerator pedal. This braking system enables extremely sensitive, yet very powerful deceleration at the same time in order to protect the load being carried and to stop the tractor immediately in dangerous situations. In addition, an automatic parking brake prevents the truck from rolling unintentionally on slopes and is released on acceleration. When operating downhill, the P120 – P350 automatically maintain their speed and are not accelerated by the weight of the transported goods. When cornering, speed is automatically adjusted. The robust cabin with optional protective windshield bars and an optional seat belt protects the operator from being harmed in case of an accident. Additionally, the cabin doors are electrically monitored and prevent the operator from travelling faster than creep speed when the doors are not properly shut. A lateral battery change allows for easy and safe handling of heavy traction batteries.

  • Automatic parking brake
  • Constant speed when travelling down on ramps
  • Speed control when cornering.
  • Robust cabin with protective bars for windshield
  • Electrically monitored cabin doors

Ergonomics

The spacious operator’s compartment with a roof hatch which can be opened provides a comfortable working environment. The decoupling of cabin and chassis and the coil springs on the drive axle prevent vibrations and shocks from being transmitted to the operator and thus minimise physical strain and fatigue in everyday work. The large curved front windshield of the P120 – P350 as well as the additional side windows on the lower half of the cabin doors provide excellent visibility in all directions. This simplifies operating manoeuvres, especially in confined areas. Moreover, optional double rear mirrors ensure a better view of the rear area of the truck as well as on the front wheel. Optional sliding doors enable easy accessing and exiting and prevent damage.

  • Operator’s cabin decoupled from chassis
  • Shock absorbers instead of leaf springs
  • Optimum all-round visibility
  • Optional double rear view mirrors
  • Optional sliding doors

Handling

The powerful electric motors of the P120 – P350 enable continuously high towing performance with maximum speeds of 22 (P120), 23 (P180) and 25 (P250 and P350) kilometres per hour. Despite heavy loads of up to 35 tons, the trucks are very agile and can be manoeuvred with ease and precision. In connection with a drive axle allowing a larger steering angle the models with a very short wheelbase ensure a small turning circle (P120 – P180). For intensive applications with long operating distances, customers can also opt for a long wheelbase, which in turn improves directional stability. In difficult operating manoeuvres that require a lot of precision, the optional double mirrors provide additional visibility. They provide optimum visibility to the rear and the front wheel and help prevent collisions. Alternatively, a rearview camera is available if frequent reversing is required.

  • Powerful electric motors
  • Small turning circle
  • Smooth and precise steering
  • Models with short or long wheelbase
  • Optional rearview camera

Service

The electric tow tractors offer service technicians easy access to all relevant components. For smooth and fast battery replacement, access to the battery compartment is possible from either the top or the side. But also with the lateral change variant, the top cover of the battery compartment can be opened for maintenance work. The bolted front screen can also be replaced in a few simple steps. The multi-disc brake is maintenance-free, as it forms a closed system with the control hydraulics into which neither dust nor dirt can penetrate.

  • Easily accessible service components
  • Maintenance-free multi-disc brake
  • Easily replaceable front windshield
  • Lateral or vertical battery change (only lateral on P350)

Technical Data

Model Load capacity/Load Overall width Travel speed, with/without load Turning radius Battery voltage/rated capacity (5h)
P120 0.3 (t) 1310 (mm) 15 / 22 km/h 2737 / 1563 (mm) 80 / 420/465 (V)/(Ah) o. kWh
P180 0.3 (t) 1310 (mm) 17 / 23 km/h 2737 / 1563 (mm) 80 / 420/465 (V)/(Ah) o. kWh
P250 (LWB) 0.3 (t) 1310 (mm) 20 / 25 km/h 3280 / 1750 (mm) 80 / 700 (V)/(Ah) o. kWh
P250 (SWB) 0.3 (t) 1310 (mm) 18 / 25 km/h 2884 / 1612 (mm) 80 / 500 (V)/(Ah) o. kWh
P300 (LWB) 0.3 (t) 1310 (mm) 20 / 25 km/h 3280 / 1750 (mm) 80 / 700 (V)/(Ah) o. kWh
P350 0.3 (t) 1310 (mm) 20 / 25 km/h 3539 / 1864 (mm) 80 / 1240 (V)/(Ah) o. kWh

Optional Equipment

Camera

The camera at the rear of the tow tractor provides the operator with increased visibility during difficult operating manoeuvres via a display.

Cab variants

The cabin is available with many different door variants, including sliding, hinged, PVC and bailed doors.

Air conditioning and heating

The combined heating and air conditioning system guarantees a comfortable working environment in the cab all year round.

Seat variants

Seats with different fabric covers and an air-suspended operator’s seat are available.

Side mirrors

Multiple exterior mirrors improve operator visibility in heavy traffic and tight spaces.

Roadworthy lighting

In this variant, the truck has a complete lighting system with headlights, turn signals, brake and reversing lights. The lamps are protected from accidents by the chassis.

Bumper

The tow tractors can be equipped with a particularly strong bumper at the front.
